Case Study Webinar Series Finite Element Method Approach to Pile Foundation of Silo Design 10 November 2020 (Tue.)
7AM(London) / 8AM(CET) / 12:30PM(New Delhi) / 2PM(Indonesia) / 3PM(SG,KL) / 6PM(Sydney) / 8PM(Wellington) | Duration : 60 min
On-Demand
OVERVIEW

In 2013, a silo with a capacity of 80,000 ton was put into operation. Both the scale of the facility and the complicated ground conditions forced the use of the finite element method at the design stage. Geodetic measurements carried out from the beginning of the investment currently constitute an extensive knowledge base and enable verification of the original computational approach. In addition, a recalculation was performed using advanced FEM options. The presentation compares various computational models of silo-ground interaction - from simple to advanced - with regard to the settlement monitoring data.

The speaker will present the problem of how much model simplifications can be made up with geotechnical experience, and when it is necessary to apply for advanced design solutions that require labor-consumption and high knowledge of the finite element method.
